True TBR72-RISZ1-LB-111-1 – Bar refrigerator – 72″ – 3 sliding glass doors – Black


Data sheet - True TBR72-RISZ1-LB-111-1

Item# : T040.TBR72RISZ1LB

Product features
3 sliding doors
Holds 125 x 6-pack cans or 78 x 6-pack bottles
Temperature range: 33-38 degrees Fahrenheit (0.5°C to 3.3°C)
9 gray PVC-coated shelves
Each shelf has 4 chrome clips for installation
Heavy-duty aluminum shelf support pilasters
Electronic controls with digital display
Cabinet illuminated by energy-saving LED lights
Double-glazed sliding doors with interior view
Self-closing doors with counterweight closure
Thermally insulated doors reduce temperature loss
Corrosion-resistant stainless steel interior
Black powder-coated exterior
Mounted on foot levelers for stabilization
Self-contained side-cooling system
Uses R-290 hydrocarbon refrigerant (ODP of 0 and GWP of 3)
Sucks in air from the front and exhausts it from the rear
Front air intake; rear air outlet
Compressor power: 1/4 HP
High-density foam insulation to maintain temperatures and provide additional structural strength to the cabinet

Brand: True
Model: TBR72-RISZ1-LB-111-1
Capacity: 20.2 cu. ft.
Can capacity: 125 six-packs
Number of shelves: 9 shelves
Door style: 3 sliding doors
Door type: Glass doors
Refrigerant type: R-290
Temperature range: 33-38 degrees Fahrenheit (0.5°C to 3.3°C)
Compressor location: Side-mounted
Compressor style: Front-breathing
Construction: Stainless steel and steel
Exterior finish: Black powder-coated
Lighting: LED
Width: 72 inches
Depth: 24 7/8 inches
Height: 34 3/4 inches
Weight: 405 lbs
Amps: 3.2 amps
Hertz : 60 Hertz
Phase : 1 phase
Voltage : 115 Volts
Power: 1/4 HP
Connector type: NEMA 5-15P
Power cord: 10 ft.
